7628 Electric Grade Fiberglass Cloth for Insulation Board High Temperature Resistance Fiberglass Fabric
Product Description
7628 is Electric Grade Fiberglass Fabric, it is a fiberglass PCB material made by high quality electric grade E glass fiber yarn. Then posted finished with resin compatible sizing. Besides the PCB application, This electric grade glass fibre fabric has excellent dimension stabilty, electric insulation, high temperature resistance, also widely applied in the PTFE coated fabric, black fiberglass cloth finish as well as other further finish. Fiberglass fabric is a woven material available in various sizes to allow custom strength, thickness, and weight in projects. Fiberglass cloth provides great strength and durability when layered with a resin to form a hardened composite.
Product Parameters
|
Fabric Code
|
Yarns
|
Warp* Weft (Fabric count) (Tex/Perinch)
|
Basic Weight
(g/m2)
|
Thickness (mm)
|
Loss of Ignition (%)
|
Width (mm)
|
|
7638
|
G75 * G37
|
(44 ± 2)*(26 ± 2)
|
255 ± 3
|
0.240 ±0.01
|
0.080 ± 0.05
|
1275 ± 5
|
|
7667
|
G67 * G67
|
(44 ± 2)*(36 ± 2)
|
234 ± 3
|
0.190 ±0.01
|
0.080 ± 0.05
|
1275 ± 5
|
|
7630
|
G67 * G68
|
(44 ± 2)*(32 ± 2)
|
220 ± 3
|
0.175 ±0.01
|
0.080 ± 0.05
|
1275 ± 5
|
|
7628M
|
G75 * G75
|
(44 ± 2)*(34 ± 2)
|
210 ± 3
|
0.170 ±0.01
|
0.080 ± 0.05
|
1275 ± 5
|
|
7628L
|
G75 * G76
|
(44 ± 2)*(32 ± 2)
|
203 ± 3
|
0.165 ±0.01
|
0.080 ± 0.05
|
1275 ± 5
|
|
1506
|
E110 * E110
|
(47 ± 2)*(46 ± 2)
|
165 ± 3
|
0.140 ±0.01
|
0.080 ± 0.05
|
1275 ± 5
|
|
1500
|
E110 * E110
|
(49 ± 2)*(42 ± 2)
|
164 ± 3
|
149 ±0.01
|
0.080 ± 0.05
|
1275 ± 5
|
|
1504
|
DE150 * DE150
|
(60 ± 2)*(49 ± 2)
|
148 ± 3
|
0.125 ±0.01
|
0.080 ± 0.05
|
1275 ± 5
|
|
1652
|
G150 * G150
|
(52 ± 2)*(52 ± 2)
|
136 ± 3
|
0.114 ±0.01
|
0.080 ± 0.05
|
1275 ± 5
|
|
2165
|
E225 * G150
|
(60 ± 2)*(52 ± 2)
|
123 ± 3
|
0.100 ±0.01
|
0.080 ± 0.05
|
1275 ± 5
|
|
2116
|
E225 * E225
|
(60 ± 2)*(59 ± 2)
|
104.5 ± 2
|
0.090 ±0.01
|
0.090 ± 0.05
|
1275 ± 5
|
|
2313
|
E225 * D450
|
(60 ± 2)*(62 ± 2)
|
81 ± 2
|
0.070 ±0.01
|
0.090 ± 0.05
|
1275 ± 5
|
|
3313
|
DE300 * DE300
|
(60 ± 2)*(62 ± 2)
|
81 ± 2
|
0.070 ±0.01
|
0.090 ± 0.05
|
1275 ± 5
|
|
2113
|
E225 * D450
|
(60 ± 2)*(56 ± 2)
|
79 ± 2
|
0.070 ±0.01
|
0.090 ± 0.05
|
1275 ± 5
|
|
2112
|
E225 * E225
|
(40 ± 2)*(40 ± 2)
|
70 ± 2
|
0.070 ±0.01
|
0.100 ± 0.05
|
1275 ± 5
|
|
1086
|
D450 * D450
|
(60 ± 2)*(62 ± 2)
|
52.5 ± 2
|
0.050 ±0.01
|
0.100 ± 0.05
|
1275 ± 5
|
|
1080
|
D450 * D450
|
(60 ± 2)*(49 ± 2)
|
48 ± 2
|
0.047 ±0.01
|
0.100 ± 0.05
|
1275 ± 5
|
|
1078
|
D450 * D450
|
(54 ± 2)*(54 ± 2)
|
47.5 ± 2
|
0.045 ±0.01
|
0.100 ± 0.05
|
1275 ± 5
|
|
1067
|
D900 * D900
|
(70 ± 2)*(69 ± 2)
|
30 ± 2
|
0.032 ±0.01
|
0.120 ± 0.05
|
1275 ± 5
|
|
1035
|
D900 * D900
|
(66 ± 2)*(67 ± 2)
|
30 ± 2
|
0.028 ±0.01
|
0.120 ± 0.05
|
1275 ± 5
|
|
106
|
D900 * D900
|
(56 ± 2)*(56 ± 2)
|
24.5 ± 1.5
|
0.029 ±0.01
|
0.120 ± 0.05
|
1275 ± 5
|
|
1037
|
C1200 * C1200
|
(70 ± 2)*(72 ± 2)
|
23 ± 1.5
|
0.027 ±0.01
|
0.120 ± 0.05
|
1275 ± 5
|
|
1027
|
BC1500 * BC1500
|
(75 ± 2)*(75 ± 2)
|
19.5 ± 1
|
0.020 ±0.01
|
0.120 ± 0.05
|
1275 ± 5
|
|
1015
|
BC2250 * BC2250
|
(96 ± 2)*(96 ± 2)
|
16.5 ± 1
|
0.015 ±0.01
|
0.120 ± 0.05
|
1275 ± 5
|
|
101
|
D1800 * D1800
|
(75 ± 2)*(75 ± 2)
|
16.5 ± 1
|
0.024 ±0.01
|
0.120 ± 0.05
|
1275 ± 5
|
|
1017
|
BC3000 * BC3000
|
(95 ± 2)*(95 ± 2)
|
12.5 ± 1
|
0.016 ±0.01
|
0.120 ± 0.05
|
1275 ± 5
|
|
1000
|
BC3000 * BC3000
|
(85 ± 2)*(85 ± 2)
|
11 ± 1
|
0.012 ±0.01
|
0.120 ± 0.05
|
1275 ± 5
|
Applications
It’s widely used in printed circuit board, fire protection board, insulation board and highly-required reinforced materials in wind power generation, aerospace, protection industries.
Features
1.High strength, heat resistance, fire-retardant and insulation.
2.High pressure strand spreading and easy for resin impregnation.
3.Treated with silance coupling agent and excellent compatibility with resins.
4.Used in the temperature from -70ºC to 550ºC.
5.Resistant to ozone, oxygen, sunlight and aging.
6.E-Grade Fabric (E-fiberglass Textile Cloth) has excellent electricity insulation property.
7.Good performance in chemical corrosion resistance.
