Products >> Roofing Tissue Mat

  • /UploadFiles/2013/2/2013110410303857760.jpg

NAME:Fiberglass Roofing Tissue mat

Number:
  • Fiberglass roofing tissue mat is mainly used as excellent substrates for waterproof roofing materials.
  • Features
    Fiberglass roofing tissue mat is mainly used as excellent substrates for waterproof roofing materials. It is characterized as high tensile strength, corrosion resistance, easy soakage by bitumen, and so on. The longitudinal strength and tear resistance can be improved further by incorporating reinforcements into the tissue across its whole width. The waterproof roofing tissue made of this substrates is not easy to crack, ageing and rot. Other advantages of waterproof roofing tissue are high strength, excellent uniformity, good weathering quality and leaking resistance.
    We can produce the goods from 40gram/m2 to 100 gram /m2,and the space between yarns is 15mm or 30mm (68 TEX)

    Model and characteristic:

    Item Unit Type
    BH-FSM50 BH-FSM60 BH-FSM90 BH-FSJM50 BH-FSJM60 BH-FSJM90 BH-FSJM90/1
    Linear density of reinforcement yarn Tex       34-68 34-68 34-68
    Space Between Yarns mm       12 30 30
    Area Weight g/m2 50 60 90 50 60. 90 90
    Binder Content % 18 18 20 18 16      20 20
    Tensile Strength MD N/5cm  ≥170   ≥180 ≥280 ≥210 ≥180 ≥280 ≥340
    Tensile Strength CMD N/5cm   ≥100   ≥120 ≥200 ≥100 ≥100 ≥200 ≥250
    Wet strength N/5cm  ≥60 ≥63 ≥98 ≥70 ≥63 ≥98 ≥120
    Standard Measurement
    Width X Length
    Roll Diameter
    Paper Core Internal Dia

    m×m

    cm
    cm


    1.0×2500

    ﹤117

    15


    1.0×2500

    ﹤117

    15


    1.0×2500

    ﹤117

    15


    1.0×2500

    ﹤117

    15


    1.0×2500

    ﹤117

    15


    1.0×2000

    ﹤117

    15


    1.0×1500

    ﹤117

    15

    *Test method referred to DIN52141, DIN52123 ,DIN52142
